Description
TP806 is a thermal receipt printer with auto-cutter, featured by high print quality, high print speed, high stability, etc. It can be used in commercial POS system, food industry and occasions which need real-time field print receipts. TP806 can connect with other equipment through parallel, serial, USB, Ethernet, bluetooth, Wi-Fi and cash drawer interfaces. And the printer drivers are available for the WINDOWS XP/WINDOWS 7/WINDOWS 8/Linux operating system.
Product information
Technical Details
| Printer Model | TP – 806 |
| Printing | Print Method Direct: Thermal Line Printing |
| Resolution: 203dpi(8dots/mm) | |
| Print Speed: Max. 300mm/s | |
| Printing Width: 48mm/72mm | |
| Interface | Internal USB, Optional – Serial, Parallel, Ethernet, Bluetooth, Wi-Fi, Cash Drawer |
| Page Mode | Support |
| Memory | RAM – 16mb |
| Flash – 32mb | |
| Fonts | Chinese GBK 16×16, 24x24doys |
| Alphanumeric ASCII 9×17, 12x24dots | |
| Code page 47 | |
| Barcode | 1D UPC-A, UPC-E, EAN8, EAN13, CPDE39,ITF, CODEBAR, CODE128, CODE93 |
| 2D PDF417, QR Code | |
| Graphics | Support bitmap printing with different density and user-defined bitmap printing. (Max size of each bitmap is 40K, the total size of bitmap is 256K) |
| Detection | Paper out detection, paper near end detection |
| Sensors | Cover open detection, cutter jam detection and Black mark detection (Optional) |
| LED Indicator | Power LED Green LED |
| Paper LED Blue LED | |
| Error LED Red LED | |
| Power Supply | Input: AC 100V-240V 50-60HZ |
| Output: DC 24V/2A | |
| Paper | Paper Type: Thermal Receipt Paper |
| Paper Width: 58mm/80mm | |
| Paper Thickness: 0.050~0.09mm | |
| Roll Paper Diameter: Max. OD-83mm | |
| Paper Load: Easy Paper Loading | |
| Paper Cut: Manual tear or Auto cutter | |
| Environment | Operation: 0°C~40°C, 20%~85%RH |
| Storage: -20°C~70°C, 5%~95%RH | |
| Physical | Dimension: 197(L) X 145(W) X 146(H)mm |
| Characteristics | Weight: 1.8KG |
| Options & Accessories | USB Cable, Serial Cable, Parallel Cable, Paper Roll, Power Adapter, CD, Quick Start Guide. |
| Software | Emulation: ESC/POS |
| Driver: Windows XP/ Vista/Win7/Win8/Win10POSReady/Linux/CUPS/OPOS/JavaPOS | |
| Software | SDK: WinCE, Win Mobile, Android, iOS |
